Escalator Library: This page contains a comprehensive compilation of information about escalators. The latest safety escalators manufactured by AmadaTECH use AmadaTECH's advanced technology and are manufactured under the supervision of our technical team.Escalator LIBRARY – Escalator Portal
AmadaTECH next GENERATION escalator technology
As Turkey’s leading company in the field of escalators, Amanda TECH is a modern and professional escalator manufacturer. We integrate design, R&D, engineering, production, sales, installation and service as one.
Our escalators are the safest on the market. They are equipped with the latest safety systems and are based on the latest technology from Amada Tech. Our technical team is the best in the business. They are highly creative, experienced, knowledgeable and expert. They have a high production process. This guarantees high performance and high quality products. Some of the key features include a built-in motor, encoder speed detection and design, high safety, high efficiency, comfort and high performance.
Amada Tech’s range of escalators is designed to meet a variety of needs and specifications. The company’s products include 30-degree, 35-degree, indoor, outdoor and heavy-duty escalators, all of which are equipped with energy-saving features to reduce operating costs.
Amada Tech escalators boast a unique power supply system that offers two key benefits: maximum passenger distribution and energy saving. These benefits are available in four performance models.
In addition to these practical advantages, Amada Tech escalators also have a beautiful design and excellent performance. The escalator’s specially designed structure makes it more stable and non-slip.
Escalator LIBRARY
Escalators General Page
The latest safety escalators manufactured by AmadaTECH utilise advanced technology from AmadaTECH, with manufacturing conducted under the supervision of our technical team. This process incorporates creativity, experience, knowledge, expertise and high manufacturing standards to ensure high performance and quality.Key features include a built-in motor, encoder speed detection and design, high safety, high efficiency, comfort and high performance.
We have escalators in various sizes, inclination angles and speed ranges. Our standard range includes models suitable for both indoor and outdoor use, with a maximum length varying according to the model. All models are designed for safety and efficiency, with built-in features such as motor, encoder speed detection and design, and high performance. The standard inclination angles are 30 and 35 degrees.
Indoor Escalators
Our new generation of escalators represents a significant advance in performance.
AmadaTECH is committed to energy efficiency and has developed a range of innovative features to reduce consumption, including AMD-Mod and LED lighting.
AMD-Mod Systems
The weight of passengers on the escalator is determined by the load information of the converter, enabling the escalator to adapt its speed to the number of passengers. This reduces energy consumption and extends the service life of the escalator.
The automatic speed reduction system ensures energy efficiency by reducing the escalator’s speed when there are no passengers.
Outdoor escalators
The outdoor escalators manufactured by the company have been engineered to provide the robust and reliable drive required for overhead walkways, shopping malls and bridges.
The escalators are equipped with features such as galvanised trusses, reinforced parts and an internal heating system, which enables their use both indoors and outdoors. These escalators are well-suited for environments with high pedestrian traffic, including overpasses, bridges, shopping malls, airports, and train stations. It is imperative to note that all escalators are supplied and installed in strict accordance with the most recent EN 115-1 2017 regulations.
Heavy Duty Escalators
Featuring galvanized truss, reinforced parts and an internal heating system, our heavy-duty escalators are suitable for both indoor and outdoor use, making them ideal for high-traffic areas such as airports, train stations and underpasses. All escalators are supplied and installed in accordance with the latest EN 115-1:2017 standard.
Moving walkway
Should you require a horizontal moving walkway to facilitate the movement of people on public transport, or an inclined moving walkway used primarily in retail and railway stations? Our range is suitable for standing or walking and can offer you the ideal product for areas with high traffic density.
Escalator Maintenance and Safety
The invention and use of escalators is intended solely for the transportation of people. The transportation of large and heavy objects on escalators may cause damage or deterioration to the unit, as well as clutter and scratches to the side and head panels. Such situations may lead to accidents and create an unsafe environment. Please see below for details of our safety precautions.
Escalator Safety
Escalators are becoming increasingly prevalent in our country, with their presence becoming a common sight in public places and shopping malls, among other locations. These devices significantly facilitate movement between different levels within buildings, offering a convenient mode of transportation.However, it is crucial to note that if these devices are not used correctly or if they are not adequately maintained, they can pose a significant safety hazard.The majority of injuries sustained by individuals are a result of falls, with hands, feet, or shoes becoming caught in the escalator mechanisms. The primary causes of these incidents are typically attributed to the behavior of passengers, equipment malfunctions, and external factors. Escalator-related accidents can result in serious medical consequences, including soft tissue damage, severe injuries, and even death.As our population, especially in rural and semi-urban areas, begins to use escalators more frequently, it is essential to understand the potential risks and take measures to prevent accidents and ensure safety.
Escalator technologies
In recent years, there has been a significant shift towards the integration of escalators and elevators into our daily lives. These advanced transportation systems have become a common sight in shopping malls and skyscrapers, a testament to the advancements in technology that have facilitated their widespread adoption. Technological progress has undoubtedly contributed to enhancing the quality of life for many individuals.Escalators have emerged as essential components in various buildings, including stores, entertainment centres, offices, and many more structures across the globe. Their sophisticated design and cutting-edge technology have led to an increase in the property value of buildings that feature them. A wide range of models is available to meet modern needs.
Optimal speed and capacity of the escalator
Escalator speed has a direct impact on its capacity as well as the space it occupies.
Furthermore, the standard transport speed is between 0.5 m/s and 0.65 m/s, which is significantly higher than the average speed of the lifting system.
Escalator step width
According to international standards, the ideal width of steps is 60 cm, 80 cm and 100 cm.
Escalator layout plan
As escalators play a vital role in the efficient movement of passengers between building floors, their precise positioning within the designated space is paramount. The installation site is meticulously prepared and designed, taking into account the customer’s specifications and the building’s intended purpose. The following installation options are available, depending on the customer’s requirements:
Information before installing moving walkways
Pre-Installation Information | Points to Consider When Installing Moving Walkways in Projects
Lubrication of escalators and moving walkways
The mechanical parts of escalators and moving walkways require regular lubrication to ensure smooth movement and reduce wear and tear. Without adequate lubrication, components are subjected to increased wear, heat, friction, corrosion and noise. This can necessitate more frequent maintenance, pose a fire safety risk and reduce the components’ service life.
Escalators and types
Different types of escalators and how they are used
In this article, we will introduce you to the different types of escalators and how they are used. This information will be useful and practical.
Escalators and escalators can be installed in various buildings and places for different purposes. They are divided into two general categories:
How do escalators work?
An escalator is supported by a structural frame known as the “escalator truss”, which houses and mounts all its mechanisms. The escalator truss comprises three primary sections: the upper section, the inclined section, and the lower section. Typically, the upper and lower sections are fixed, while the central section can be adjusted to provide variable heights.
How to choose the location of the escalator?
Public movement is an important factor in determining the optimal location for an escalator.
When installing an escalator in a shopping mall, it is advisable to avoid locations near fast-moving stores to minimise congestion.
Escalators and elevators in a shopping mall should be located near the main entrance and along the primary routes of the building’s infrastructure.
Ensure there is sufficient free space on the upper and lower landing platforms.
Escalator moving in reverse direction
Should your escalator suddenly change direction or speed, this is most likely indicative of a malfunction. There are several potential causes for this malfunction. Firstly, the issue may be due to a faulty part. Secondly, the part may have worn out or broken over time. Thirdly, the problem may be due to improper maintenance. For example, the maintenance technicians may have incorrectly installed the parts that are causing the problem.
Information on pre-installation of escalators
When installing escalators in projects, the following points must be taken into account:
Escalator support structure
An escalator is supported by a structural frame known as the “escalator support”, which houses and mounts all its mechanisms. This support is divided into three primary sections: the upper section, the inclined section, and the lower section. The upper and lower sections are typically fixed, while the central section can be adjusted to provide variable heights.
Types of handrails for escalators
The handrail is composed of 10mm-thick tempered glass, with a height of 90cm. The transparency of the glass gives the escalator a modern appearance, making it the most popular type of handrail among architects and interior designers.It is manufactured in individual pieces of 1200mm in standard sizes, with no protective caps or partitions at the joints, providing a cleaner and less expensive look. The handrail can be supplied in stainless steel or a combination of glass and stainless steel, and lighting is available as an option. The lighting is located beneath the handrail, enhancing the aesthetic appeal of the handrail and escalator as a whole.
Advantages of inverter on escalators
Inverter escalators and escalators as a whole are characterised by a gradual increase in voltage and frequency in accordance with a set acceleration. At the point of initiation, the inverter supplies the motor drive with an adjustable, controlled voltage, thereby ensuring a smooth take-off. Consequently, the main circuits and other key components are not subjected to sudden forced movement, which significantly increases their service life. Furthermore, this system helps to minimise the risk of people falling by preventing a sudden stop when turning off.
Escalator Coating Requirements
Escalator coverings represent a vital component of escalators and walkways, with manufacturers prioritising both aesthetic appeal and safety standards in their designs. These coverings are typically constructed from stainless steel sheets of varying grades, chosen to meet the specific requirements of each project. This approach ensures not only a visually appealing finish but also ease of maintenance and enhanced durability. Stair handrails, supports, decks and landing decks are covered with stainless steel cladding sheets.Proper covering of escalator elements provides better protection of the interior from the effects of factors such as water, snow, dust, etc. from the environment.In addition, the covering of moving components of escalators
Cleaning and using escalators
Escalator and moving walkway owners frequently invest in specialised escalator cleaning equipment (or contract cleaning services) that utilises a “dry” cleaning method. This method involves the deployment of a machine that is integrated into the lifting equipment during operation. The synchronised movement of the escalator and the cleaning machine effectively removes deeply embedded dirt from the tread area, which is typically inaccessible to conventional brushes.
Escalator handrail safety device
In order to prevent individuals from stepping on the lower outer surface and climbing over the outer surface of the escalator, it is necessary to install an anti-climbing device(s). This device is located on the outer lower surface, starting at a height of 1000 ± 50 millimetres from the surface of the finished basement floor. The length of the device is 1000 millimetres, parallel to the handrail. To ensure the safety of passengers’ hands and fingers, the height of this device can be increased by a maximum of 25 millimetres and lowered by 150 millimetres below the handrail. The distance between the handrail and the anti-climbing device is 80 millimetres.
